6V 100A Low Ripple Electrolysis Rectifier with 220V Single Phase Input and Local Panel Control

Certification : CE ISO9001

Model Number : GKD6-100CVC

MOQ : 1pcs

Delivery Time : 5-30 working days

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Price : 500-600$/unit

Supply Ability : 200 Set/Sets per Month

Place of Origin : China

Brand Name : Xingtongli

Packaging Details : strong plywood standard exporting package

Contact Now

6V 100A Low Ripple Electrolysis Rectifier with 220V Single Phase Input and Local Panel Control

The 6V 100A low ripple electrolysis rectifier is designed to provide stable and precise DC power for electrolysis and electrochemical applications. It features 220V single phase AC input, air cooling, and local control for simple and convenient operation. The low ripple output helps ensure stable current delivery and consistent electrolysis performance, making it suitable for electrolytic processing, metal refining, surface treatment, and other industrial electrochemical processes.

Technical Specifications
  • Input Power: single-phase 220V AC ±10%, 50/60Hz
  • Output Capability:
    • Voltage: DC 0-6V continuously adjustable
    • Current: DC 0-100A continuously adjustable
    • Power: Max 600W (6V *100A)
  • Regulation Accuracy: Voltage ±1%, Current ±1%
  • Efficiency: ≥85% (IGBT high-frequency soft-switching technology)
  • Cooling System: Intelligent forced air cooling (temperature-controlled variable-speed fans, low noise)
  • Protection Features: Over-voltage, over-current, short-circuit, overheating, phase loss, and input surge protection
  • Control Modes: Auto-switching between CV/CC modes; supports local keypad or remote RS485 communication (Modbus protocol)；local panel control
  • Display Interface: LED/liquid crystal screen for real-time voltage, current, and status alerts
  • Operating Temperature: -10℃ to +50℃
  • Protection Rating: IP21 (dust and drip-proof)

Key Advantages
  • Flexible Adaptation: CC/CV auto-switching ensures precise control for electroplating processes.
  • Energy Efficiency: IGBT high-frequency inversion reduces energy loss, saving 10%-15% compared to traditional SCR rectifiers.
  • Compact Design: Space-saving and lightweight, suitable for workshops or labs.
  • Smart Thermal Management: Fans adjust speed based on load temperature, balancing cooling and noise.
  • High Compatibility: Wide input voltage range (±15%) accommodates grid fluctuations.

Applications
  • Precision Electroplating: Gold/silver plating, PCB electroplating, and other current-sensitive processes.
  • Small-Scale Electrolysis: Lab-based water electrolysis, precious metal refining.
  • Surface Treatment: Anodizing, electrophoretic coating, metal polishing.
  • R & D & Education: Electrochemical experiments in universities and research institutes.
  • 6V 100A Low Ripple Electrolysis Rectifier with 220V Single Phase Input and Local Panel Control
  • 6V 100A Low Ripple Electrolysis Rectifier with 220V Single Phase Input and Local Panel Control
