12V 1000A Industrial Electroplating Rectifier 380V Three Phase Air Cooled DC Power Supply

Certification : CE ISO9001

Model Number : GKD12-1000CVC

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Price : 850-1250$/unit

Supply Ability : 200 Set/Sets per Month

MOQ : 1pcs

Delivery Time : 5-30 working days

Place of Origin : China

Brand Name : Xingtongli

Packaging Details : strong plywood standard exporting package

Contact Now

12V 1000A Industrial Electroplating Rectifier 380V Three Phase Air Cooled DC Power Supply

The 12V 1000A industrial rectifier is designed to provide stable and reliable DC power for electroplating and other electrochemical applications. It features a 380V three phase AC input and air cooling, providing efficient heat dissipation and dependable performance during continuous operation. The rectifier can be used for chrome plating copper plating nickel plating zinc plating anodizing and various industrial DC power applications.

Technical Specifications
  • Input Power: three-phase 380V AC ±10%, 50/60Hz
  • Output Capability:
    • Voltage: DC 0-12V continuously adjustable
    • Current: DC 0-1000A continuously adjustable
    • Power: Max 12KW (12V *1000A)
  • Regulation Accuracy: Voltage ±1%, Current ±1%
  • Efficiency: ≥85% (IGBT high-frequency soft-switching technology)
  • Cooling System: Intelligent forced air cooling (temperature-controlled variable-speed fans, low noise)
  • Protection Features: Over-voltage, over-current, short-circuit, overheating, phase loss, and input surge protection
  • Control Modes: Auto-switching between CV/CC modes; supports local keypad or remote RS485 communication (Modbus protocol)；local panel control
  • Display Interface: LED/liquid crystal screen for real-time voltage, current, and status alerts
  • Operating Temperature: -10℃ to +50℃
  • Protection Rating: IP21 (dust and drip-proof)

Key Advantages
  • Flexible Adaptation: CC/CV auto-switching ensures precise control for electroplating processes.
  • Energy Efficiency: IGBT high-frequency inversion reduces energy loss, saving 10%-15% compared to traditional SCR rectifiers.
  • Compact Design: Space-saving and lightweight, suitable for workshops or labs.
  • Smart Thermal Management: Fans adjust speed based on load temperature, balancing cooling and noise.
  • High Compatibility: Wide input voltage range (±15%) accommodates grid fluctuations.

Applications
  • Precision Electroplating: Gold/silver plating, PCB electroplating, and other current-sensitive processes.
  • Small-Scale Electrolysis: Lab-based water electrolysis, precious metal refining.
  • Surface Treatment: Anodizing, electrophoretic coating, metal polishing.
  • R & D & Education: Electrochemical experiments in universities and research institutes.
  • 12V 1000A Industrial Electroplating Rectifier 380V Three Phase Air Cooled DC Power Supply
  • 12V 1000A Industrial Electroplating Rectifier 380V Three Phase Air Cooled DC Power Supply
